Bathology Spectrum 320

Steam Room / In-Shower Light, Recessed, 5" Diameter Metal / Glass Lens

Model
Spectrum 320

Lighting elegance engineered by Bathology!

Designed for bathers in search of a recessed downlight that nearly disappears into their ceiling, the Spectrum 320’s slender profile, small scale appearance and frosted glass lens makes it the popular choice of architects, interior designers and bathers.

MSRP
$447.76
Your Price
$313.43

Spectrum 320 is a low-voltage, recessed, ceiling-mounted light U.L. listed for wet locations. Utilizing a unique leaf spring mounting mechanism, the near-flush trim contains a frosted glass lens with a clear center to cast the ideal downward shine. Perfect for steam bathing environments, the Spectrum 320 overcomes sloped ceiling room designs with its innovative 35-degree lamp angle adjustment technology.

Created for both remodeling and new construction, the Spectrum 320 housing comes pre-wired and ready to install. The electronic low-voltage transformer (120VAC/12VAC) is conveniently located atop the housing with an integral junction box. Available in both Satin Nickel and White finishes.

Consider the Spectrum 320 for new construction or remodeling projects where insulation may be set-back a minimum of 3" from the housing, the maximum ceiling thickness does not exceed 1-1/4" and there exists 6" of installation height.

  • Wet-Environment Rated
  • Sloped Ceiling Adjustment
  • Universal Appeal
  • Both Functional and Ambiance Lighting
  • Aesthetically Pleasing Trim and Lens
  • Easy Re-Lamping
  • Low-voltage Operation (12VAC)
  • U.L. Listed, Suitable for Wet Locations
  • Near-Flush Trim/Lens
  • 35 Degree Vertical Lamp Adjustment
  • Ceramic Bi-Pin Socket with Aluminum Heat Shield
  • Housing, 4" Thermally protected 22 gauge galvanized steel with integral transformer, 10-1/2"L x 4-3/4"W x 5-1/4"H
  • Trim, metal with frosted glass lens, 5" diameter, 1/8" profile
  • Lamp, 50 Watt, 12VAC, MR16, GU5.3 Base, clear flood halogen
  • Silicone sealant, .5 ounce tube
  • Installation template
  • Installation and operation manual
Swipe horizontally to reveal full table content.
Model Spectrum 320
Fixture Type Recessed Ceiling Downlight, Halogen
Dimming With Low Voltage Magnetic Type Dimmer
Insulation Contact Non-IC Rated
Minimum Installation Height 6”
Maximum Ceiling Thickness 1-1/4”
Rough-In Cut-Out 4-3/8”
Housing Length 10-1/2”
Housing Width 4-3/4”
Housing Height 5-1/4”
Transformer 120V AC to 12V AC 50VA, Thermally Protected, Magnetic
Shipping Weight 6 lbs
Testing U.L. Listed, CSA, Suitable for Wet Locations
Trim Steel, Electrostatic Powder Paint
Trim Profile 1/8”
Trim Diameter 5”
Lens Etched Frosted Tempered Glass with Clear Center
Lamp 50 Watt 12VAC MR16, GU5.3 Base, Halogen
Lamp Current 4.25 Amps
Lamp Life 3000 Hours
Lamp Socket Bi-pin with Ceramic Insulator and Aluminum Heat Shield
Color Temperature 3000K
Color Rendering Index 100 Ra8
Beam Angle 36 Degree
Lumen 850
